Sand and Dust Blasting Test Chamber | ASLI Environmental Dust Testing Equipment

APPLICATION

The Sand and Dust Test Chamber is designed to simulate environments with floating or cyclone dust, making it ideal for testing a wide range of automotive components. These include headlights, instruments, seat belts, seat adjusters, electrical components, and more, ensuring their durability and resistance in dusty conditions.

SHARE AS

REQUEST A QUOTE

FEATURES

Powerful Dust Spraying System: The chamber allows for independent operation of No.1, No.2, and No.3 floating dust levels on the gauge panel.

Vibration Device: Ensures consistent dust density for repeatable and accurate testing every time.

Precise Dust Concentration Monitoring: Reduces the risk of incorrect readings due to improper operation, ensuring reliable results.

Standards Compliance: Fully meets DIN, IEC, GB, ISO, and JIS standards for dust testing.

Computer-Controlled System: Allows real-time monitoring and control via computer connection.

Easy Maintenance: Designed for simple and efficient dust cleaning after testing.

Synchronous Resonance Function: Guarantees uniform dust concentration throughout the testing process.

Contact:

For more information, please contact:

Email: contact@aslitesting.com

TECHNICAL PARAMETERS

Model	DT-F1	DT-F2	DT-F3	DT-C1	DT-C2
Remark	F for floating dust			C for cyclone dust
Concentration of Sand and Dust	F1: 60000mg/m³	F2: 3000mg/m³	F3: 100mg/m³	C1: 5000mg/ m³, 5m/s	C2: 100mg/ m³, 10m/s
Internal Dimension WxHxD (mm)	1000x1000x1000			1000x1000x1000
External Dimension WxHxD (mm)	1600x1800x1300			1650x1850x1450
Temperature Range	RT(25℃±15℃), or lab temperature			RT(25℃±15℃), or lab temperature
Humidity Range	35~90% R.H., or lab humidity			35~90% R.H., or lab humidity
Talcum Powder Dosage(Kg/m ²)	2 ~4
Metal Net Mesh Standard Diameter(μm)	50
Diameter Between Metal Wires(μm)	75
Powder Spray & Dust Fall Mode	1. Dust fall freely: adopt centrifugal fan to blow the sand or dust to the 1/5 of roof, then fall freely. 2. Blow the sand or dust: pressure spray dust from the bottom, multi-steps pressure adjustable
Test Standard	Meet JIS, ISO, IEC60529,DIN40050,GB2423 test standard
Power	AC 220V(±10%), 1∮ 3 Lines,50/60HZ ;
